      Product description

      All ships with a gross tonnage of 150 or more, and navigating in international waters, are required to have daylight signalling lamp on board. This ALDIS Portable daylight signalling lamp (morse lamp) with 24 VDC and 60 W power is certified by the HK (Japanese government) as compliant to the relevant SOLAS provisions and the IMO (International Maritime Organisation) Resolution MSC.95(72) – Performance Standards for Daylight Signalling Lamps – (Adopted on 22 May 2000). All ships with a gross tonnage of 150 or more, and navigating in international waters, are required to have such a light on board. A copy of the certificate will be attached to the product shipment.

      • ALDIS Lamp with 5 m cable
      • Container Box (BOX-1D)
      • Battery (PXL12090F2-W)
      • Battery Charger (BCN-24S)
      • Connection cable with plugs 1,5 m
      • 3 pieces of spare halogen lamp

      Construction

      • Simplified signal operation Equal or better transmission rate of 12 words per minute can be achieved.
      • A special halogen lamp is used for getting a long life and stable luminous flux.
      • A very light weight of the lamp housing due to aluminium material and therefore easy operation.
      • Neutral filter and colour filter can be attached easily.

      Technical Information

      • Voltage [VDC]: 24
      • Lamp: Halogen lamp
      • Power [W]: 60
      • Luminous intensity [cd]: 60000
      • Beam angle [°]: 6
      • Signal reaching distance at daytime [NM]: 3
      • Protection Class: IP 44
      • Weight lamp [kg]: 2,55
      • Overall weight (Box, Battery, Lamp) [kg]: 13,6

      Accessories

      • Flush mounted connection receptacle for ALDIS lamp (non water tight, IP20), Partnumber: 1st12RE-254FPA
      • Surface mounted connection receptacle for ALDIS lamp (water tight, IP65), Partnumber: 1st12RE-254PA

      Manufacturer information

      • Manufacturer: Sanshin Electric Corporation
      • Partnumber: SPS-10A
      Tags:ACR (27)ALDIS (12)CPF54 (27)Faro di ricerca per cabina a LED (27)HRL-2070MU (27)HRL-2070U (27)LED Cabin Searchlight (27)LED Cabin Zoeklicht (27)Projecteur de cabine à LED (27)Proyector LED de cabina (27)RCL-100 LED Searchlight (27)RCL-300A (27)RCL-600A (27)Sanshin (27)Scheinwerfer (27)Searchlight (12)SPS-10A (12)Suchscheinwerfer (27)Wireless Control LED Cabin Searchlight (27)Yachtscheinwerfer (27)Светодиодные фары для яхты (27)

      Specifications

      Article number
      1st12SPS-10A
